ABOUT 4.49 TON CAR AND MACHINERY HYDRAULIC TILTING RAMPLESS TRAILER – 1200MM CAGE AND FOUR SETS LADDER RACKS ALSO AVAIL 3.5TON ATM

4.49 ton Car and Machinery Hydraulic Tilting Rampless Trailer – also available 3.5ton ATM

Includes 13,500lb Elec Winch housed in Trailer Deck, Spare Wheel, Mudflaps, 6mths Registration

Brand new model 4490 kg hydraulically operated fully galvanised car or machinery trailer requiring no ramps for loading. Unique design allows for quick loading and unloading. Wheel arches only extend 165 mm above the trailer deck which allows opening of most any car door without interference.

Payload capacity 3400 kg and with the 2005 mm wide clearance between mudguards, almost any motor vehicle will be able to be transported on this unique trailer system. To view this amazing trailer in action just click on the link here https://youtu.be/wvIzsKXScU4

All Wide Bay Trailers come with a One Year Factory Backed Warranty for absolute peace of mind when you purchase.

SPECIFICATIONS

  • 16.6ft Hot Dipped Galvanized Tandem Hydraulic Powered Car/Machinery Carrier
  • DECK SIZE: 5 x 2m (16.6 x 6.6ft) clear of any obstacles.
  • Includes 13,500lb (6 Ton) electric Winch with wireless remote and wired in remote
  • Wheel guards only 165 mm above trailer deck eliminating door damage to vehicles
  • No Ramps Required, easy, efficient, fast loading
  • 125mm Structural chassis supper strong and flexible
  • Under body extra bracing with long lasting construction
  • ATM 3500KG TARE: 1000kg PAYLOAD: 2500kg (Pricing on Request)
  • ATM 4400KG TARE: 1100kg PAYLOAD: 3300kg
  • Fully Welded Heavy Duty Body then hot dipped galvanised
  • Integrated winch box built into front of trailer deck with 13,500lb winch included
  • Hydraulic Ramp with Push button Controls for Ease of Loading
  • Fold Down Tie down Points (12 in total) 6 along each sides in C-section channel for straps or chains
  • Heavy Duty DEXTER Wheel Bearings (4490kg Rated)
  • 4-wheel x 12inch Electric Brakes
  • Emergency Brake Away System Fitted
  • Steel Toolbox on drawbar houses Hydraulic Pump, Electric Motor and Deep Cycle Battery
  • Multi-volt 12/24v LED lights with Marker Lights both sides. ADRs Complied.
  • 70mm x 4.4t Quick Release Coupling
  • 1900mm Long Draw Bar – 125mm C-section
  • 4490kg Tow hitch brake/handbrake
  • 52mm Solid Axles. Rocker Roller Suspension with Heavy Duty 9 Leaf Springs (4500kg rated)
  • LAND-CRUISER 6 stud 15-inch white Sunraysia wheels.
  • Brand new * Ply 225 R15 Light Truck Tyres
  • Includes swing up 10inch heavy duty Jockey Wheel
  • Includes Spare Wheel
  • Includes Mudflaps
  • Includes 6mths Rego
